Filament Spectrum PA6 CF15 1.75mm BLACK 0.75kg
Filament Spectrum PA6 CF15 1.75mm BLACK 0.75kg
Filament Spectrum PA6 CF15 1.75mm BLACK 0.75kg
Filament Spectrum PA6 CF15 1.75mm BLACK 0.75kg
Filament Spectrum PA6 CF15 1.75mm BLACK 0.75kg
Filament Spectrum PA6 CF15 1.75mm BLACK 0.75kg
Filament Spectrum PA6 CF15 1.75mm BLACK 0.75kg

Filament Spectrum PA6 CF15 1.75mm BLACK 0.75kg

  • Spectrum PA6 CF15 is a black, high-temperature PA6-based construction material modified to achieve better performance. Filling with carbon fibres increases significantly the mechanical strength of the polyamide the material is based on.
92,90 €
/ pcs.incl. VAT
large quantity in stock
large quantity in stock
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Express checkout 1-Click(without registration)

Filament Spectrum PA6 CF15

High temperature construction material

Spectrum PA6 CF15 is a black, high-temperature PA6-based construction material modified to achieve better performance. Filling with carbon fibres increases significantly the mechanical strength of the polyamide the material is based on. The filaments specific quality is the moisture absorption reduced by half and the water absorption time is four times lower than that of the pure PA6. Printing does not require a heated chamber and no deformation occurs. The material is compatible with the HIPS and PVOH support materials.

In addition, Spectrum PA6 CF15 features an exceptionally low linear shrinkage (up to 0.1%), a high deformation temperature (240oC) and low thermal expansion coefficient (0.4 10-5/K). Parts made of Spectrum PA6 CF15 allow for long-term operation at elevated temperatures up to 150°C (20.000h) and up to 180°C for a short time operation (max. 200h).

To attain the very attractive properties of Spectrum PA6 CF15, as regards the technical aspects, you need to follow the basic storage rules for such materials (in a dry and dark place with humidity below 15%). To obtain the best parameters of the printed object possible, it is recommended to dry the material prior to work.

Tip: Due to the essential content of chopped carbon fire, it is recommended to use nozzles with diameters exceeding the standard value of 0.4mm. The presence of carbon fibre may also cause wear of standard nozzles; thus it is recommended to use hardened steel or ruby nozzles for prolonged application of Spectrum PA6 CF15.


Key features:

  • exceptionally low processing (linear) shrinkage of 0.1 %
  • high temperature up to 180°C for short-time operation (max. 200h)
  • high temperature up to 150°C for long-time operation (20.000h)
  • heat distortion temperature – HDT A 200°C (ISO 75)
  • water absorption below 0.3% (23°C / 24h)
  • abrasion resistance
  • high mechanical strength
  • very robust interlayer lamination
  • high creep resistance
  • high hardness and rigidity of the printed items

Applications:

  • production of gear wheels and racks, sweep-off gears and guide rolls operated in elevated temperatures up to 150°C on a prolonged basis and up to 180°C on a short-time basis
  • all types of ring and plate seals with an increased chemical and corrosion resistance
  • end-use parts
  • tooling
  • functional prototyping
  • industrial modelling

Packaging

Filament is reeled on the neat, transparent spool. Each spool contains information on the type of material, diameter and recommended printing temperature. Filament is vacuum-packed with a moisture absorber. Whole product packed in the original, foiled Spectrum Filaments packaging.

Symbol
5903175653734
Producer code
5903175653734
General information
Material group
PA
Color
Black
Spectrum color name
Black
Diameter
1.75mm
Dimensional tolerance
± 0.03mm
Verify your spool - preview of the diameter course on the entire length of the spool
YES
Density
1.25 g/cm³
Net weight
750g
Total weight
1150g
Recommended print settings
Printing temperature
260-290°C
Heated bed
necessary
Heated bed temperature
<80°C
Printing speed
30-60mm/s
Closed chamber
Not necessary
Dimensions of the spool
Outer diameter
200mm
Width
55mm
Inner diameter
52mm
Empty spool weight
± 220g
